COMPACT 80V pellet fireplace insert
L 79x48x65 cm
Wood-burning insert with ventilated and channeled hot air with reversible door entirely in ceramic glass.
Thanks to its simple lines, it easily adapts to any type of environment.
The beauty of simplicity: combustion chamber complete with catalyst-flame arrester lined with CMtech 2, ceramic refractory, with cast iron fire bed. Wide view of the fire.
Available with black painted steel frame.
Structure in painted steel
Ventilated hot air
Ductable
Combustion chamber in cast iron
Door opening with silk-screened glass
Wide view of the fire
classe di qualità D.M. 186 -7/11/2017 | ||
potenza termica globale (al focolare) | 11,1 | kW |
potenza certificata | 9,5 | kW |
CO misurato (al 13% di ossigeno) | 0,09 | % |
rendimento | 85,3 | % |
consumo combustibile | 2,68 | kg/h |
portata in massa dei fumi | 8 | g/s |
temperatura dei fumi | 205 | °C |
tiraggio (depressione al camino) | 12 | Pa |
tubo uscita fumi | Ø 200 | mm |
sez. interna canna fumaria | Ø 20 | cm |
altezza min. canna fumaria | 3 | m |
superficie riscaldabile a potenza certificata | 109 | *mq |
peso netto | 120 | kg |
peso con imballo | 130 | kg |
Classe Energetica: A+
Certificazione EcoDesign 2022
Livello di prestazione ambientale ««««
