    Caminetti Montegrappa MB MEGAIDRO W 24.9 / 29.8 kW Hydro Wood Fireplace – 5 Stars

    6006011400

    The Caminetti Montegrappa MB MEGAIDRO W is a large hydro wood-burning fireplace designed to heat both the central-heating water circuit and the room. Available as W31 with 24.9 kW and W35 with 29.8 kW certified output, it delivers up to 17.2 kW to water, carries 5-Star environmental certification and offers an indicative heating capacity of up to approximately 342 m²

    Cornice
    Power version
    Domestic water kit
    Thermoregulator kit
    Primary air regulation kit
    Primary and secondary circuit separator kit
    €3,880.00
    Quantity

    help_outlineAsk about product
    Caminetti Montegrappa MB MEGAIDRO W 24.9 / 29.8 kW Hydro Wood Fireplace – 5 Stars

    Caminetti Montegrappa MB MEGAIDRO W 24.9 / 29.8 kW Hydro Wood Fireplace – 5 Stars

    The Caminetti Montegrappa MB MEGAIDRO W is a large hydro wood-burning fireplace designed to heat both the central-heating water circuit and the room. Available as W31 with 24.9 kW and W35 with 29.8 kW certified output, it delivers up to 17.2 kW to water, carries 5-Star environmental certification and offers an indicative heating capacity of up to approximately 342 m²

    I accept privacy policy rules

      Buy with confidence

    WE TAKE ALL MEASURES TO MAKE YOUR PURCHASE SAFE

      WE SHIP WORLDWIDE

    WE LEAVE THE DELIVERY OF ORDERS TO THE BEST COURIERS

      Return policy

    (edit with the Customer Reassurance module)

    Description

    Caminetti Montegrappa MB MEGAIDRO W Hydro Wood-Burning Fireplace – 5 Stars

    The Caminetti Montegrappa MB MEGAIDRO W is a large hydro wood-burning fireplace designed to transfer a significant part of the heat produced by wood combustion to the central-heating water circuit while still providing substantial direct heat to the room.

    It is available as MB MEGAIDRO W31 and MB MEGAIDRO W35, providing respectively 24.9 kW and 29.8 kW certified heat output. Heat output to water reaches 13.5 kW on the W31 and 17.2 kW on the W35.

    The fireplace features a large rectangular full ceramic-glass door with vertical sliding opening for wood loading and tilt opening for easier cleaning. The combustion chamber is lined with CMtech® refractory material.

    Why choose the Caminetti Montegrappa MB MEGAIDRO W?

    • Hydro wood fireplace: heats both the central-heating water circuit and the room.
    • Two output versions: W31 with 24.9 kW and W35 with 29.8 kW certified output.
    • Up to 17.2 kW to water: significant contribution to the hydronic heating circuit.
    • Up to 12.6 kW to the room: substantial direct heating in the installation area.
    • 5-Star environmental certification: according to Italian D.M. 186/2017.
    • Indicative heating area up to approximately 342 m²: suitable for homes with high heating requirements.
    • Large panoramic ceramic glass: provides an extensive view of the flames.
    • Vertical sliding opening: convenient for everyday wood loading.
    • Tilt opening: makes glass cleaning easier.
    • CMtech® combustion chamber: thick refractory lining.
    • Open or closed expansion vessel: dedicated optional accessories are available.
    • Optional domestic hot water kit: suitable for additional system configurations.

    Technical specifications

    SpecificationMB MEGAIDRO W31MB MEGAIDRO W35
    Total heat input28.9 kW35.0 kW
    Certified heat output24.9 kW29.8 kW
    Heat output to room11.4 kW12.6 kW
    Heat output to water13.5 kW17.2 kW
    Efficiency86%85%
    CO at 13% O₂0.0353%0.0300%
    Primary particulate matter at 13% O₂14 mg/Nm³20 mg/Nm³
    OGC at 13% O₂22 mg/Nm³8 mg/Nm³
    Maximum operating pressure3 bar3 bar
    Fuel consumption6.8 kg/h8.2 kg/h
    Flue gas mass flow22.7 g/s24.9 g/s
    Flue gas temperature182 °C200 °C
    Required draught11 Pa11 Pa
    Flue outletØ 250 mmØ 250 mm
    Internal chimney sectionØ 25 cm / 25 × 25 cmØ 25 cm / 25 × 25 cm
    Minimum chimney height5 m5 m
    Air inlet ductsØ 100 mmØ 100 mm
    Indicative heating areaUp to approx. 286 m²*Up to approx. 342 m²*
    Net weight409 kg409 kg
    Packed weight432 kg432 kg
    Environmental certification5 Stars5 Stars
    ComplianceEN 16510 / EcodesignEN 16510 / Ecodesign

    *Actual heating capacity depends on building insulation, climate zone, heated volume, required temperature and heating-system design.

    W31 or W35: which version should you choose?

    The MB MEGAIDRO W31 provides 24.9 kW certified output, including 13.5 kW transferred to water and 11.4 kW directly to the room.

    The MB MEGAIDRO W35 increases certified output to 29.8 kW and heat output to water to 17.2 kW, making it more suitable for larger properties or higher heating requirements.

    How does the MB MEGAIDRO W hydro fireplace work?

    MB MEGAIDRO W transfers part of the heat produced by wood combustion to the central-heating water circuit. With the correct hydraulic design, it can therefore contribute to radiators, fan coils or other compatible hydronic heating terminals.

    The system must be designed by a qualified professional according to building heat demand, hydraulic configuration, other heat generators and required safety devices.

    Large panoramic ceramic-glass door

    The large rectangular ceramic-glass door provides an extensive view of the fire. The vertical sliding mechanism makes wood loading convenient, while tilt opening provides easier access for cleaning.

    CMtech® combustion chamber

    The combustion chamber is lined with CMtech®, a thick refractory material designed to withstand the high temperatures generated inside the firebox.

    Open or closed expansion vessel and domestic hot water

    Caminetti Montegrappa offers dedicated optional accessories for installations with open or closed expansion vessels.

    An optional domestic hot water production kit is also available, allowing the appliance to be adapted to different heating-system configurations.

    How much space can the Caminetti Montegrappa MB MEGAIDRO W heat?

    The W31 is suitable for an indicative heating area of up to approximately 286 m², while the W35 can reach approximately 342 m².

    For a hydro fireplace, these figures should only be considered indicative. Correct sizing must primarily be based on the actual heat demand of the building and heating system.

    Installation and chimney system

    Both versions feature a Ø 250 mm flue outlet. The manufacturer specifies an internal chimney section of Ø 25 cm or 25 × 25 cm and a minimum chimney height of 5 metres.

    Installation must be carried out by qualified personnel and include all control, protection, safety and expansion devices required by current regulations and system design.

    5 Stars, Ecodesign and incentives

    MB MEGAIDRO W31 and W35 are 5-Star certified according to Italian D.M. 186/2017. Official Caminetti Montegrappa documentation also includes Ecodesign certification and specific conformity documents for Italian Conto Termico 3.0 applications.





    International Shipping & Warranty

    • Product Specifications: All wood and pellet products in our catalog are official Italian versions and strictly comply with Italian technical standards and certifications. We cannot supply products configured for foreign market regulations.

    • Shipping: Our website automatically processes orders within Italy only. For shipping to EU or Non-EU countries, we provide quotes upon request via email. Alternatively, customers may arrange their own courier pickup (Ex-Works).

    • Warranty & Service: On-site warranty service is valid strictly within Italy. Local service centers outside Italy will not cover parallel-imported products. In case of documented manufacturing defects, warranty support is limited exclusively to supplying replacement parts from Italy (local labor and technician costs remain the buyer's responsibility).

    Please check product compatibility with a local installer before purchasing. For any further information, please contact our customer service.
