Cadel Maya Idro 24 is a slim 24 kW ventilated hydro pellet stove designed for restricted spaces, corridors and passage areas. It delivers 18.3 kW nominal useful water output and features integrated Wi-Fi and Bluetooth, GoFast rapid ignition, an included hydraulic kit, a cast-iron burning pot and top or rear flue outlet. 22 kg hopper, up to 94% efficiency, A+ energy class and Italian 5-star environmental rating.
Buy with confidenceWE TAKE ALL MEASURES TO MAKE YOUR PURCHASE SAFE
WE SHIP WORLDWIDEWE LEAVE THE DELIVERY OF ORDERS TO THE BEST COURIERS
Return policy(edit with the Customer Reassurance module)
Cadel Maya Idro 24 is a slim 24 kW ventilated hydro pellet stove designed to supply a domestic heating system while requiring relatively little installation depth.
Its slim construction makes it particularly suitable for corridors, passage areas and rooms where available space is limited.
Maya Idro 24 delivers 18.3 kW nominal useful water output and features integrated Wi-Fi and Bluetooth, GoFast rapid ignition, an included hydraulic kit, temperature sensors and daily and weekly programming.
One of the main advantages of Maya Idro 24 is its slim construction, designed to simplify installation where available depth is limited.
Cadel specifically identifies the model as suitable for corridors and passage areas, making it an attractive solution where a conventional hydro pellet stove would occupy too much usable floor space.
Maya Idro 24 transfers a substantial proportion of the energy generated by pellet combustion to the water circulating through the domestic heating system.
At nominal operation, 18.3 kW of useful heat is transferred to the water, while reduced useful water output is 3.1 kW.
The stove can therefore supply radiators and other compatible hydronic heating terminals when the system is correctly sized.
Maya Idro 24 is also a ventilated hydro pellet stove, meaning that part of the available heat is released directly into the room where the appliance is installed.
Cadel Maya Idro 24 is supplied with an integrated hydraulic kit, helping simplify connection to the domestic heating system.
The hydraulic layout must nevertheless be correctly designed and checked by qualified personnel.
Maya Idro 24 features integrated Wi-Fi and Bluetooth connectivity, allowing compatible Cadel systems to manage operating schedules, temperatures and main functions more flexibly.
GoFast technology is designed to speed up pellet ignition and reduce the time required for the appliance to reach operating conditions.
The stove offers daily and weekly programming together with an external thermostat connection for more flexible integration with household heating requirements.
The integrated hopper has a capacity of 22 kg.
Cadel specifies pellet consumption of approximately 1 to 5.4 kg/h, corresponding to indicative autonomy of approximately 4 to 22 hours depending on output and operating conditions.
Maya Idro 24 features an Ø 80 mm flue outlet that can be configured at the top or rear of the stove.
A dedicated Ø 50 mm combustion air inlet is also provided.
The top outlet can be especially useful in slim installations because it may reduce the installation depth required behind the appliance.
Cadel specifies an indicative heating volume ranging from approximately 137 to 672 m³, corresponding to approximately 51 to 248 m².
These figures are indicative. Actual heating performance depends on building insulation, climate zone, ceiling height, hydraulic system configuration and actual heat loss.
When sizing a hydro pellet stove, particular attention should be paid to the 18.3 kW nominal useful water output and the actual requirements of the heating system.
| Brand | Cadel |
| Model | Maya Idro 24 |
| Certificate model | MAYA IDRO 24 T3 |
| Type | Slim ventilated hydro pellet stove |
| Fuel | Ø 6 mm pellet |
| Nominal heat output | 24 kW |
| Nominal heat input | 26.2 kW |
| Reduced heat output | 4.9 kW |
| Nominal useful water output | 18.3 kW |
| Reduced useful water output | 3.1 kW |
| Nominal efficiency | 92% |
| Reduced-load efficiency | 94% |
| Indicative heating volume | 137 - 672 m³ |
| Indicative heating area | 51 - 248 m² |
| Pellet hopper | 22 kg |
| Pellet consumption | 1 - 5.4 kg/h |
| Indicative autonomy | 4 - 22 h |
| Net weight | 167 kg |
| Flue outlet | Ø 80 mm, top or rear |
| Combustion air inlet | Ø 50 mm |
| Burning pot | Cast iron |
| Wi-Fi | Integrated |
| Bluetooth | Integrated |
| GoFast | Yes |
| Hydraulic kit | Included |
| External thermostat connection | Yes |
| Water temperature sensor | Yes |
| Air temperature sensor | Yes |
| Programming | Daily and weekly |
| Energy class | A+ |
| Italian environmental rating | 5 stars D.M. 186 |
Maya Idro 24 must be correctly sized and connected to the domestic heating system by qualified personnel.
Building heat demand, radiator output, system water volume, hydraulic configuration and chimney sizing must all be assessed before installation.
The choice between the Ø 80 mm top or rear flue outlet provides additional installation flexibility, particularly where available depth is limited.
