Palazzetti Ecofire Nadine TC 13 Pro3: 13 kW sealed ductable ceramic pellet stove

Palazzetti Ecofire Nadine TC 13 Pro3 is a 13 kW sealed ductable pellet stove designed to distribute warm air to multiple rooms while maintaining refined ceramic styling and advanced Palazzetti technology.

The Pro3 system uses three independent fans: one for the main installation room and two dedicated to the rear Ø80 mm hot-air ducts.

Why choose Palazzetti Nadine TC 13 Pro3

• 13 kW nominal heat output.
• Minimum heat output of approximately 2.8 kW.
• CC50 sealed combustion.
• Direct outdoor combustion-air intake capability.
• Steel structure with elegant ceramic cladding.
• Double-door design: aesthetic + technical door.
• Balanced Door.
• Pro3 with three independent fans.
• Main-room fan plus two ducting fans.
• Two rear Ø80 mm hot-air ducts.
• Zero Speed Fan.
• Digital touch control panel.
• Daily and weekly programming.
• Designed for optional Universal Gateway.
• T3 technology.
• Complete Burning System.
• Self Cleaning System.
• Speedy Clean.
• Quick Start.
• Star pellet-feed system.
• 18 kg pellet hopper.
• Maximum indicative burn time of approximately 28 hours.
• A+ energy class.
• Italian 5-star environmental rating.

Pro3 independent hot-air distribution

The Pro3 system uses three independent fans.

One fan heats the main installation room, while two additional fans are dedicated to the rear Ø80 mm hot-air ducts.

This configuration allows warm air to be distributed to two separate rooms or zones while maintaining independent management of the main-room ventilation.

Ceramic cladding and double-door design

Nadine TC 13 Pro3 combines a steel structure with ceramic cladding and a double-door arrangement with separate aesthetic and technical doors.

CC50 sealed combustion: what does it mean?

Nadine TC 13 Pro3 is a CC50 certified sealed pellet stove.

CC50 means that combustion-chamber airtightness is verified at a pressure difference of up to 50 Pa according to EN 16510.

Combustion air can therefore be supplied directly from outdoors rather than being taken from the installation room.

This is particularly relevant in modern well-insulated buildings, low-energy homes and properties with controlled mechanical ventilation. Installation compatibility must always be assessed by a qualified installer.

Zero Speed Fan

The main-room fan features Zero Speed Fan.

When operating conditions permit, forced ventilation can be completely switched off, increasing acoustic comfort and favouring heat distribution through natural convection and radiation.

T3 technology

Nadine TC 13 Pro3 uses Palazzetti's T3 technology, based on four enlarged flue-gas tubes designed for efficient heat exchange and simplified cleaning.

Self Cleaning System

The Self Cleaning System automatically cleans the pellet burn pot by periodically discharging combustion residues.

Complete Burning System

The Complete Burning System promotes more complete pellet combustion and helps reduce residual ash production.

Speedy Clean and Quick Start

The latest-generation Speedy Clean system provides front access to the flue-gas circuit, simplifying routine cleaning and maintenance.

Quick Start is designed to reduce ignition time and allow the stove to reach normal operating conditions more quickly.

Performance and pellet consumption

Nadine TC 13 Pro3 delivers a 13 kW nominal heat output and can modulate down to approximately 2.8 kW.

Palazzetti technical documentation specifies approximately 90.5% efficiency at nominal output and 90.9% at partial load.

Pellet consumption ranges from approximately 0.64 to 2.99 kg/h. The hopper has a capacity of 18 kg, providing a maximum indicative burn time of approximately 28 hours.

Palazzetti Ecofire Nadine TC 13 Pro3 technical specifications

Installation and ducting

Nadine TC 13 Pro3 uses an Ø80 mm flue outlet and can draw combustion air directly from outdoors.

The two rear hot-air ducts use Ø80 mm connections.

The chimney and ducting system must be correctly designed and installed by qualified personnel in accordance with current regulations and Palazzetti's technical instructions.

A+ energy class, 5-star rating and incentives

Palazzetti Ecofire Nadine TC 13 Pro3 is rated A+ for energy efficiency and achieves the Italian 5-star environmental rating under D.M. 186.

Palazzetti documentation refers to Conto Termico 3.0, Ecobonus and Bonus Casa for qualifying biomass heating installations. Eligibility depends on the type of project, the appliance being replaced and compliance with all applicable technical and administrative requirements.

For further information, see our guide to Conto Termico 3.0 and incentives for biomass heating appliances.
