DISEC STONE Rok Sferik BD131-25D1 – Anti-Pull Euro Cylinder Protector, 31 mm ATRA/DIERRE Fixing Centres
DISEC STONE Rok Sferik BD131-25D1 mechanical Euro cylinder protector for compatible ATRA/DIERRE locks with 31 mm fixing centres. Carbonitrided steel body with hemispherical profile and anti-pull edge, 85 × 68 mm escutcheon and M6 Flex System mounting. Grade 4 burglary resistance declared by DISEC. Offered in bronze and polished brass.
TRUSTED EXPERIENCE SINCE 1913Over 100 years of experience in hardware, tools and technical products.
PHYSICAL STORE & CUSTOMER SUPPORTWe also have a physical store in La Loggia (Turin): real people ready to help before and after your
ORDERS PREPARED WITH CAREWe prepare every order with care
Description
DISEC STONE Rok Sferik BD131-25D1 – Anti-Pull Euro Cylinder Protector
The DISEC STONE Rok Sferik BD131-25D1 is a mechanical security protector for Euro profile cylinder locks with compatible ATRA/DIERRE mounting arrangements. Manufactured from carbonitrided steel, it features a hemispherical profile and an anti-pull edge, designed to resist cylinder breaking, extraction and drilling attempts. DISEC specifies grade 4 burglary resistance.
STONE protection and Flex System mounting
The hemispherical profile reduces exposed gripping surfaces for tools used during forced-entry attempts. The anti-pull edge provides an additional structural feature to resist forces applied when attempting to remove the protector.
The Flex System uses reinforced fixing screws to improve mounting resistance compared with conventional fasteners. The front key opening allows normal insertion and operation of the cylinder key.
Dimensions and technical specifications
| Type | Hemispherical anti-pull mechanical protector |
|---|---|
| Application | Euro cylinder – ATRA/DIERRE mounting arrangement |
| Protector material | Carbonitrided steel |
| Dimensioned circular envelope | Ø54 mm |
| Escutcheon dimensions | 85 × 68 mm |
| Overall projection | 27 mm |
| Nominal size | 25 mm |
| Fixing centres | 31 mm |
| Fixing thread | M6 |
| Mounting system | Flex System |
| Additional protection | Anti-pull edge |
| Burglary resistance grade | 4 |
| Orderable finishes | Bronze, polished brass |
Compatibility and installation
The BD131-25D1 is intended for compatible ATRA/DIERRE locks with 31 mm fixing centres. It differs from the BD121 model, which uses standard 38 mm fixing centres.
Before installation, check the cylinder position relative to the external door panel, the escutcheon clearance and the fixing-hole arrangement. Compatibility must be assessed according to the actual lock model.
A DISEC cylinder protector spacer is also listed in the Matteoda catalogue and can be ordered separately. Its suitability must be confirmed for the specific installation.
Before ordering: check the ATRA/DIERRE mounting arrangement, 31 mm M6 fixing centres and protector dimensions against the existing door. Contact Matteoda customer service for technical assistance and estimated delivery times.
Product Details
708.0843021
Specific References
- ean13
- 8029470063737
