DISEC PS0600 – Internal Release Lever Protector for Up-and-Over Garage Door Locks
DISEC PS0600 internal mechanical protector for the release lever of up-and-over garage door locks. Shields the internal release mechanism and helps prevent unauthorised operation through holes made in the outer door panel. Keyless mechanical device with overall dimensions of 166 × 60 mm. Designed for compatible FASEM, ISEO, PREFER, VIRO, NEMEF and CISA lock configurations. Check lock geometry before ordering.
TRUSTED EXPERIENCE SINCE 1913Over 100 years of experience in hardware, tools and technical products.
PHYSICAL STORE & CUSTOMER SUPPORTWe also have a physical store in La Loggia (Turin): real people ready to help before and after your
ORDERS PREPARED WITH CAREWe prepare every order with care
Description
DISEC PS0600 – Internal Release Lever Protector for Garage Door Locks
The DISEC PS0600 is an internal mechanical protector for the release lever of locks fitted to up-and-over garage doors. It shields the internal release mechanism, helping resist attempts to operate the lever from outside through openings made in the door panel.
Protection for the internal release mechanism
Some garage door locks are equipped with an internal release lever that allows the door to be opened from inside.
The PS0600 is installed around the lock to shield this lever, making it more difficult to reach and operate using tools inserted through the outer metal panel.
It is a passive mechanical protector, not an additional keyed lock. It is designed to protect the existing release mechanism without replacing the main door lock.
Dimensions and technical specifications
| Product type | Mechanical release lever protector |
|---|---|
| Overall height | 166 mm |
| Overall width | 60 mm |
| Mounting position | Internal, around the lock mechanism |
| Operation | Mechanical, no key required |
| Application | Release levers on compatible garage door locks |
Compatibility and installation
The PS0600 is intended for compatible FASEM, ISEO, PREFER, VIRO, NEMEF and CISA garage door lock configurations. Compatibility depends on the release lever position, lock geometry and available mounting clearance.
Before installation, compare the protector with the existing lock and ensure that normal release operation from inside the garage remains possible.
Before ordering: check the lock model and release lever position. The protector does not include the lock and must not prevent emergency opening from inside. Contact Matteoda for technical assistance and estimated delivery times.
